full color curved led display for advertising HM4 P50 high transparent soft LED mesh screen for media facade
Function and Technology Character Introduction:
1. nnovative installation methods, decorated up quickly, easily, flexible;
2. flushbonading wireless control technology is specialized for the screen, easily
3. Processing technology for high speed video, can show all kinds of videos, unique effect, highly impelling
4. Each module adopts a buckle design, which is easy to disassemble, and the strips and points are pluggable, making maintenance easier;
5. The installation structure is simple and does not affect the original wall structure.
6. Our company uses imported raw materials. Both the cable and PC's fire rating can reach V0, allowing customers to use our led grid screen more reliably and safely.
7. The mesh screen can be folded, rolled up, and curved to freely combine with the facade of most buildings.
8. Thus, the application range is larger than the conventional screen. Such as glass curtain walls, irregular building facades, landscape project, science, and technology museum, stage background, bar, and decorative lighting.
Products Applications:
Used in large outdoor venues such as city squares, high-end hotel exterior walls, outdoor advertising displays, film and television centers, and sports centers.
SPECIFICATIONS Parameters:
| Product name | 20 Round Project LED Mesh Screen |
| Product specifications | P50 |
| Application | indoor / outdoor |
| Product installation | Steel support |
| Product load-bearing wire | 2.0mm steel wire fixed (2 single moduler) |
| Single module width | 0.3 m / block |
| Maximum length of a single module | 8 meters |
| Lights per square meter | 400 lights / flat |
| Power per square meter | 120W / square |
| Weight per square meter | 4.5KG/square |
| Flatness of the lamp | less than 1mm |
| Viewing distance | 50 meters or more |
| Viewing angle | <140 ° |
| Signal transmission distance | within 90 meters of Category 5 network cable |
| Overall transparency | 73% |
FAQ
1) Q:Do you test all your goods before delivery?
A:Yes, we have 100% test before delivery.
2) Q:Do you offer any other components of led display screen?
A:Yes, we offer all the components of led display, such as modules, control cards, video processors, and power supplies, etc... one stop service.
3) Q:What kind of led display we provide?
A:We can provide many types of led screen: for example: indoor Led screen,outdoor Led screen, fixed led screen, rental led screen, led poster, irregular Led screen ect.
4) Q:How to install the shipped LED display box into a complete LED screen?
A:Before shipment, we will classify each material and affix corresponding material identification and number on each package. When shipment, we will provide structure drawing, installation drawing and data connection drawing. In addition, our service engineers are on line 24 hours a day and can consult relevant questions at any time.
